Internet in my cabin (120ft/ 40m from house)

Hi all,

I’m running a cat 6 cable 50M from my router (in the house) down the garden to my wooden cabin. In order to use wireless Internet in the cabin, do I just need to plug the cat 6 cable into another wireless router? Will the network have the same name? Sorry for such a basic question.
Can anyone recommend a cheap router? The cabin is only 3x4M

Thanks!!
«1

Comments

  • flaneurs_lobster
    flaneurs_lobster Posts: 6,038 Forumite
    Sixth Anniversary 1,000 Posts Photogenic Name Dropper
    edited 26 May at 3:31PM
    There was a similar enquiry here a while ago, one of these at £15 was recommended

    https://www.currys.co.uk/products/tplink-tlwa855re-v2-wifi-range-extender-n300-singleband-10175583.html

    The details there give the more usual configuration (connect device wirelessly to primary router to boost signal and has an Ethernet port to attach another device).

    I believe that it can work aboutface, so hardwire to router via Ethernet port, gives you a local wireless access point.

    Can anyone confirm?
  • Bartoni79
    Bartoni79 Posts: 130 Forumite
    Sixth Anniversary 10 Posts Name Dropper
    I’m looking for a good internet connection and assumed that using an extender 40m away would give me a poor signal signal plus the router is at the front of ky hoyse and the cabin at the rear so it will need to go through at least 3 solid walls. i had an extender in my old terraced house and it barely made it up 3 floors…
  • QrizB
    QrizB Posts: 16,972 Forumite
    10,000 Posts Fourth Anniversary Photogenic Name Dropper
    Image 8 of 8 on the Currys site states "build-in access point mode" and AP mode is what you've described.
    N. Hampshire, he/him. Octopus Intelligent Go elec & Tracker gas / Vodafone BB / iD mobile. Ripple Kirk Hill member.
    2.72kWp PV facing SSW installed Jan 2012. 11 x 247w panels, 3.6kw inverter. 33MWh generated, long-term average 2.6 Os.
    Not exactly back from my break, but dipping in and out of the forum.
    Ofgem cap table, Ofgem cap explainer. Economy 7 cap explainer. Gas vs E7 vs peak elec heating costs, Best kettle!
  • Ayr_Rage
    Ayr_Rage Posts: 2,426 Forumite
    1,000 Posts Second Anniversary Photogenic Name Dropper
    edited 26 May at 3:55PM
    You just need a wireless access point, an old router can be repurposed to do that if you are even a little bit tech savvy.

    I would set it as a different SSID (network name) and use different WiFi channels to the main router in the house, that way you know which router you are actually connected to at any time.

    Your device should automatically switch to the access point with the best signal as you move between house and cabin.
  • QrizB
    QrizB Posts: 16,972 Forumite
    10,000 Posts Fourth Anniversary Photogenic Name Dropper
    Bartoni79 said:
    I’m looking for a good internet connection and assumed that using an extender 40m away would give me a poor signal signal plus the router is at the front of ky hoyse and the cabin at the rear so it will need to go through at least 3 solid walls. i had an extender in my old terraced house and it barely made it up 3 floors…
    We're not suggesting that you use an extender. We're suggesting that you run the cable and put a WiFi access point on the end of it.

    N. Hampshire, he/him. Octopus Intelligent Go elec & Tracker gas / Vodafone BB / iD mobile. Ripple Kirk Hill member.
    2.72kWp PV facing SSW installed Jan 2012. 11 x 247w panels, 3.6kw inverter. 33MWh generated, long-term average 2.6 Os.
    Not exactly back from my break, but dipping in and out of the forum.
    Ofgem cap table, Ofgem cap explainer. Economy 7 cap explainer. Gas vs E7 vs peak elec heating costs, Best kettle!
  • flaneurs_lobster
    flaneurs_lobster Posts: 6,038 Forumite
    Sixth Anniversary 1,000 Posts Photogenic Name Dropper
    Bartoni79 said:
    I’m looking for a good internet connection and assumed that using an extender 40m away would give me a poor signal signal plus the router is at the front of ky hoyse and the cabin at the rear so it will need to go through at least 3 solid walls. i had an extender in my old terraced house and it barely made it up 3 floors…
    I'm suggesting using the tp-link hardwired to your router at the end of your cable in the cabin. It's a cheap wireless access point in this mode.
  • Bartoni79
    Bartoni79 Posts: 130 Forumite
    Sixth Anniversary 10 Posts Name Dropper
    Ah got it!!!! I see… Thanks
  • gefnew
    gefnew Posts: 919 Forumite
    Part of the Furniture 500 Posts Name Dropper
  • WIAWSNB
    WIAWSNB Posts: 342 Forumite
    100 Posts Name Dropper
    edited 26 May at 6:13PM
    These TP WiFi extenders come in two varieties. One is purely WiFi to WiFi daisy-chaining. They don't get very far before signal drops off.
    The other has an Ethernet socket, which I understand receives the Ethernet signal from your main router, and then 'WiFi's it to your devices. So you'd run an Ethernet cable from your router to the TP, and then the TP would provide the WiFi signal. That's what you have in mind?
    In which case, run your Cat 6 cable - or buy a looong Ethernet ditto - to your cabin - 50m shouldn't be an issue - and plug it into your TP. It'll then broadcast that WiFi to your devices in there.
    They have an App that can be used to set it up.
    Any 'fixed' devices in your cabin, then you can use an Ethernet 'Switch' at the end of this Cat/Ethernet cable to run a cable to your 'fixed' device, and another to the TP for WiFi.
    Alternatively, since you clearly have mains power in your cabin, you could possibly use 'Powerline Adaptors' which employ your existing mains supply? Not sure how far they work, but it could save you running an extra cable?
    Eg: TP-LINK TL-PA7017
    'Wired' is always better. :smile:


  • Murmansk
    Murmansk Posts: 1,120 Forumite
    Part of the Furniture 500 Posts Name Dropper
    My understanding is that powerline adaptors tend to cut the speed rather a lot so I think the Cat5 cable is a far better idea.
